Integrando un innovativo software ai nostri Beacon BLE possiamo creare una rete MESH intelligente, adatta a tutti gli ambienti industriali. I TAG wireless sono autonomi al 100%.

Il software Wirepass Mesh integrato consente l'individuazione ed il tracciamento in tempo reale di persone ed apparecchiature su lagra scala. Facilmente implementabile, questo sistema di localizzazione plug-and-play per interni trasforma i dati grezzi inviati dai beacon in coordinate GPS (latitudine e longitudine), grazie allo strumento Wirepas Positionning Engine. TAG posizionati su persone o dispositivi mobili, consentono di ottenere un posizionamento preciso da 5 a 10 metri.

Se non trovi il prodotto che fa per te, contattaci e troveremo insieme la soluzione migliore.









INDOOR LOCATION EVALUATION KIT
People and asset indoor location solution

Compatible in harsh industrial environments, the indoor location solution will allow you to consult in real time and in a 100% autonomous way, the position of people and equipment.

Based on Mesh technology developed by WIREPAS, this indoor location solution in addition works with ELA Innovation’s beacons. Composed of a set of tags that can be mobile or fixed, this bidirectional network makes it possible to emit light or sound signals through dynamic interactions.

The battery-less infrastructure, which requires no connection, facilitates the deployment of the solution and ensures a highly competitive total acquisition cost.

KIT COMPOSITION

- 25 Tags Blue PUCK ID Mesh (with NFC setting)
- 10 mobiles Tags
- 15 anchors Tags
- 1 plug and play gateway
- 1 NFC reader
- 3 months of access to the Wirepas Network Tool (Cloud + PC): Vizualisation of Tag positions in real time, vizualisation of the state of the network, importing floorplans, placing and updating of the anchor nodes, 3 months of access to Wirepas technical support





BLUE COIN ID MESH
Beacon Bluetooth Low Energy MESH– NFC

• Location accuracy: 5 to 10 meters
• Lifecycle: up to 6 years with a transmission period every 6 hours
• Operating modes: Non- router mode - Mobile point: periodic transmission of the location / identifier
• PICK TO LIGHT system
• Advertising BLE frame
• Option: Accelerometer 3 axes (Blue PUCK ID+ Mesh ref: IDF25451)
• Robust industrial casing ( 36 mm - H: 10 mm - W: 11 g) – IP68 waterproof - White DELRIN Housing
• Integrated NFC chipset
• Operating temperature : -30°C à +70°C

PDF documentation




BLUE PUCK ID MESH
Beacon Bluetooth Low Energy – NFC

• Location accuracy: 5 to 10 meters
• Lifecycle: up to 20 years with a transmission period every 6 hours
• Operating modes:
  - Router mode - Anchor: data feedback on the network
  - Non- router mode - Mobile point: periodic transmission of the location / identifier
• PICK TO LIGHT system
• Advertising BLE frame
• Option:
  - Buzzer (Blue PUCK BUZZ ref: IDF25245)
  - Accelerometer 3 axes (Blue PUCK ID+ Mesh ref: IDF25451)
• Robust industrial casing ( 57 mm - H: 18 mm - W: 36 g) – IP68 waterproof - White DELRIN Housing
• Integrated NFC chipset
• Operating temperature : -40°C à +85°C

PDF documentation


BLUE SLIM ID MESH
Beacon Bluetooth Low Energy label – NFC

• Bluetooth Low Energy label
• Location accuracy: 5 to 10 meters
• Lifecycle: up to 2,5 years with a transmission period every 6 hours
• Operating modes:Non- router mode - Mobile point: periodic transmission of the location / identifier
• Integrated NFC chipset
• Advertising BLE frame
• Option: Accelerometer 3 axes (Blue SLIM ID+ Mesh ref: IDF3444)
• ABS Housing 56 x 30,6 x 2,4 mm - Ultra Slim: 2.4mm adhesive face
• Operating temperature : -20°C à +55°C
• Integrated NFC chipset


PDF documentation
